Pedrollo QEM 200 Control Panel

Control Panel for Borehole Pump Pedrollo QEM 200

The QEM series control panel is made of self-extinguishing thermoplastic and is designed to protect pumps from overloads and short circuits. It allows connection of a float switch, pressure relay, or other automatic sensors for pump operation.

Main parameters:

• Pump motor power: 1.5 kW (2 HP)

• Power supply: 220 V

• Rated current: 13 A

• Capacitor: 60 μF

Components:

• Switch with fuse

• Operation mode selector

• Terminal box for connecting pump and float switch, pressure relay, etc.

• Thermal protection with manual reset

• Pump ON indicator lamp

• Capacitor

Features:

• Protects the pump from overloads and short circuits

• Allows connection of automatic sensors (float switch, pressure relay)

Services included with purchase:

• Warranty and post-warranty service

• Installation, commissioning, and start-up
